DWC-XSDE08MiC1

MEGApix Ai CaaS Vandal Dome, Star-Light Plus, 4K , Star-Light Plus, 2952x2320 @ 30fps, Ai Deep Learning, 1TB Storage, DW Spectrum IPVMS Server Installed, 2.7-13.5mm Autofocus Varifocal P-Iris Lens, 100ft Smart IR, T-WDR, 3D-DNR, True D&N, Alarm In/RelayOut,Triple Codecs (H.265, H.264, MJPEG) with Simultaneous Streaming, Two Way Audio, PoE Class 3 and DC12V, ONVIF Compliant, IP67, IK10, NDAA, TAA, 5 Year Warranty.
Features
  • Serverless Architecture - Eliminates the need for external servers, enabling faster deployment and reducing infrastructure. costs.
  • 4K Resolution at 30fps - Delivers ultra-clear video for detailed surveillance in real time.
  • Star-Light Plus Technology - Captures color images in near-total darkness, enhancing visibility in low-light environments.
  • AI Deep Learning Object Detection - Accurately identifies people, vehicles, and other objects with up to 40 customizable detection zones, reducing false alarms.
  • Built-in 1TB Storage - Supports up to 90 days of retained video, minimizing reliance on external storage solutions.
  • DW Spectrum Preloaded - Enables out-of-the-box operation with seamless integration into existing DW systems.
  • Vari-focal P-Iris Lens with Autofocus - Allows remote zoom and focus adjustments for optimal image clarity anytime.
  • True Wide Dynamic Range (WDR) - Ensures clear images in challenging lighting conditions, such as backlit scenes.
  • Two-Way Audio - Enables direct communication between the monitoring station and the camera location.
  • NDAA/TAA Compliant - Suitable for federal and government installations requiring strict compliance.

Easy setup (no manual analytics calibration)

DW’s Ai allows operators to choose what to detect and where; with a user-friendly and straightforward UI, users can set up multiple scenarios specific to their monitoring needs without complex calibration.

Object Classification

DW's Ai software processes video streams to detect and classify every object appearing in the detection zone. Our Deep Learning engines perform object detection (DL Object tracker), automatically classifying the objects in the scene: people, cyclists, cars, buses and vans, trucks, motorcycles, bicycles and bags.

Optimized Ai for the edge

MEGApix Ai's analytics engine is especially designed for the edge, working on the camera side to substantially reduce bandwidth consumption and accelerate response times.

Ambarella CV22 and CV25 chips with CVflow®

Ambarella’s CV22 and CV25 chips combine image processing, real-time 30fps 4K and 5MP video encoding and CVflow® architecture to provide the deep neural network (DNN) processing required for the next generation of intelligent IP cameras.

Camera as a System

The CaaS™ solution supports multiple cameras in the same network, and unlimited systems all accessible and manageable via DW Spectrum® client, app, and DW Cloud™.

All-in-one cameras that do not require NVR’s, DVR’s or on-premise servers

MEGApix® CaaS™ cameras act as an all-in-one solution, handling recording, notifications, management and monitoring all accessed remotely, with no need for a dedicated server or remote recorder.

Deep Learning

DW’s Ai intelligent algorithms offer deep learning with better object detection and identification of environmental elements. The result is a substantial reduction in false alarms for control room operators and security personnel. Allowing only valid events to filter through increases efficiency and productivity, and reduces unnecessary costs.

Star-Light Plus™ color in darkness technology

Star-Light Plus™ color in near-total darkness technology provides crisp, clear images in the absence of ambient light.

Higher resolution = more pixels, more forensic details

DW's technology delivers high-resolution crystal-clear images, making more minor details appear clear and sharp when zooming into the scene.

Specifications

Active Pixels 3840 (H) x 2160 (V)
Frequency 50Hz
Image sensor 4K 1/2.8" CMOS sensor
Star-Light Plus™ sensor
Maximum resolution 4K
Minimum Scene Illumination in color 0.0 lux (B/W)
0.09 lux (color)
Scanning System Progressive scan
Test Video Output Local video output CVBS 1.0V p-p (75Ω), 4:3 aspect ratio
Total Pixels 3864(H) x 2228(V)
Stream speed
Local server recording 1TB local memory for recording
Number of DW Spectrum® CaaS™ licenses included 1 DW Spectrum® CaaS™ license included
Lens
Advanced Lens Features Auto focus
Motorized zoom
P-iris
Focal Length 2.7mm ~ 13.5mm
Horizontal Field of View (HFOV) 90.3° ~ 33.1°
Illumination Distance 100' range Smart IR™
Lens Type Vari-focal Lens
Vertical Field of View (VFOV) 18.9°~49
I/O
Audio compression G.711
Event triggers Illegal login
Motion Alarm
Network disconnection
Schedule
Sensor detection
Temperature anomaly
I/O Alarm in/out 1 input
1 output
I/O Audio in/out 1 input (1.0Vms, 3K ohm)
1 output
Intelligent Video Analytics
Advanced video analytics AI-based object tracking
Analytics filters Zones and lines, tamper, metadata, intrusion, line crossing, counting, counting lines, appear, disappear, stopped, enter, exit, direction, tailgating, dwell, logical rules
Operational
3D digital noise reduction Smart DNR™ 3D Digital Noise Reduction
Auto gain control Auto
Day and night Auto day/night
Day (color)
Night (B/W)
De-fog Yes
Mirror/flip Yes
Motion Detection Yes
Operational Notifications Alarm output activation
Email
FTP server
Privacy Zones 16 programmable privacy masks
Sharpness Yes
Shutter Mode Anti-Flicker
Auto
Manual
Slow Shutter
Shutter Speed 1/15 ~ 1/32000
Slow Shutter Speed Off
x10
x2
x3
x5
x6
x7.5
White Balance Yes
Wide Dynamic Range (WDR) True WDR 120dB
Network
Bitrate Control Multi-streaming CBR/VBR at H.265 (controllable frame rate and bandwidth)
IP IPv4
LAN 1000Base-T (1Gbps)
Network resolution H.264: 3840x2160, 2592x1944, 2560x1440, 1920x1080, 1280x720, 640x480, 640x360, 352x288, 352x240
H.265: 3840x2160, 2592x1944, 2560x1440, 1920x1080, 1280x720, 640x480, 640x360, 352x288, 352x240
MJPEG: 1920x1080, 1280x720, 800x600, 768x432, 704x576, 704x480, 640x480, 640x360, 352x288, 352x240
Network Web Viewer Google Chrome® browser
Linux® OS
Mac® OS
Microsoft Edge® browser
Mozilla Firefox® browser
Safari® browser
Windows OS
Protocol DDNS
DHCP
DNS
FTP
HTTP
HTTPs
ICMP
NTP
ONVIF
RTP (UDP/TCP)
RTSP
SMTP
SNMPv1/v2/v3 (MIB-2)
SSL
TCP/IP
UDP
Zeroconf (AutoIP)
Security 802.1x
Digest authentication (ID/PW)
HTTPS (TLS)
IP filtering
Stream Speed Up to 30fps at all resolutions
Streaming Capability Dual-stream at different rates and resolutions
Video Bitrate 100Kbps ~ 25Mbps, multi-rate for preview and recording
Video Compression Type H.264
H.265
MJPEG
Video Management Software Any ONVIF conformant CMS
DW Spectrum®
ExacqVision Technologies
Environmental
Compliance CE  FCC  NDAA Comp  ONVIF  UL Listing
Environmental Operating Humidity 10-90% (non-condensing)
Environmental Operating Temperature -4°F ~ 122°F (-20°C ~ 50°C)
Mounting Accessories (Required/Optional) Optional. Sold separately
Mechanical
Camera Dimensions (H X W X D) 4.92" x 3.62" (125 x 92 mm)
Camera Weight 1.14 lbs (0.51kg)
Housing Vandal Dome
Housing Color White
IK rating IK10 Rated
IP rating Weather Resistant (IP67)
Materials Aluminum die-casting
Electrical
American wire gauge (AWG) 30M
Cable type #18
Power Consumption DC12V: 10.2W, 850mA
PoE: 12.5W, 260mA
Power Requirements Adapter not included
PoE
General
Warranty 5 Year Warranty
